3PKT100408 / 3PKT100404 Milling Inserts

The 3PKT100408 3PKT100404 Milling Inserts are high-performance carbide inserts designed for indexable milling cutters. Manufactured from premium carbide with advanced PVD coating, the 3PKT100408 3PKT100404 Milling Inserts deliver excellent wear resistance, toughness, and long tool life. Featuring a triangular geometry with three cutting edges, the 3PKT100408 3PKT100404 Milling Inserts ensure efficient chip evacuation, reduced cutting forces, and stable performance in steels, stainless steels, and cast irons.

These inserts are commonly used in face milling, shoulder milling, and slotting applications. Thanks to their sharp edges and optimized chipbreaker design, they provide superior surface quality in both roughing and semi-finishing operations. The 3PKT100404 version has a smaller 0.4 mm corner radius, suitable for fine finishing, while the 3PKT100408 version with a 0.8 mm corner radius offers stronger edges for heavier cuts.

The 3PKT series is widely used in automotive, mold-making, and precision engineering industries where productivity, stability, and cost efficiency are essential.

Code Breakdown

• 3P – Triangular insert with 3 cutting edges

• K – Insert style designation

• T – Insert clamping type

• 10 – Insert size: 10 mm IC

• 04 / 08 – Corner radius (0.4 mm / 0.8 mm)

Key Features of the Milling Inserts

• Triangular geometry with 3 effective cutting edges

• Premium carbide substrate with advanced coating

• Optimized chipbreaker for smooth chip flow

• Available in two corner radii: 0.4 mm and 0.8 mm

• Suitable for steels, stainless steels, and cast irons

Equivalent Milling Inserts (Other Brands)

• Iscar: 3PKT 100408 IC908 (Iscar official site)

• Sandvik: XDKT / 3PKT 10 series

• Kennametal: 3PKT Beyond series

• Seco: 3PKT10 platform inserts

Application Guidelines

• Cutting speed (steel): 160–280 m/min

• Depth of cut: 0.3–3.0 mm

• Feed per tooth: 0.15–0.5 mm

• Applications: face milling, shoulder milling, slotting, contouring
