MGEHR2020-2T30 External Grooving and Parting Tool Holder

MGEHR2020-2T30 External Grooving and Parting Tool Holder

Description (≈170 words):
The MGEHR2020-2T30 is a versatile external grooving and parting tool holder designed for CNC and conventional lathes. Built with a 20×20 mm shank, it provides rigidity and precision, making it suitable for parting-off, slotting, and grooving operations. This holder is specifically designed for MGMN 2.0 mm carbide inserts, allowing accurate narrow grooving and efficient material removal.

The 2T30 designation indicates a 2.0 mm insert width with a maximum cutting depth capacity of 30 mm, making it ideal for medium-duty applications requiring deeper cuts. The optimized clamping system ensures stable insert holding, reduced vibration, and effective chip evacuation, improving surface finish and tool life.

The MGEHR2020-2T30 is commonly used in industries such as automotive, aerospace, and precision engineering, where accuracy and repeatability are critical. Paired with MGMN200 inserts, it ensures consistent performance in steels, stainless steels, and cast irons.

Code Breakdown:

• M – Clamping method: screw clamp

• G – Insert type: grooving

• E – Insert geometry: external slotting

• H – External grooving/parting holder style

• R – Cutting direction: right-hand

• 2020 – Shank size: 20×20 mm

• 2T30 – For MGMN 2.0 mm inserts, max depth 30 mm

Key Features:

• External grooving and parting tool holder

• Shank size: 20×20 mm for rigidity

• Right-hand cutting direction

• Supports MGMN 2.0 mm inserts

• Cutting depth capacity: up to 30 mm

• Secure clamping reduces vibration

• Suitable for steels, stainless steels, and cast irons

Compatible Inserts:

• MGMN200 series
